Teseo suspension LED lamp

Teseo suspension with lens

Suspension LED lamp

Suspension for indoors, minimalist design with 84x84 mm square section tube, in white metal painted. On request for contract supplies, special finishings can be customized. Arranged with a balancing system for automatic steel wires regulation.

Available with LED module, driver included, 220Vac and 27° lens (700 lm luminous flux) or with LED module, driver not included, and 700mA 27° lens (700 lm luminous flux)

Available in two different colour temperatures: 3000K and 4000K



TECHNICAL DATA

SYMBOLS

PHOTOMETRIC CURVE

T004 LB K3

LED module 3 CREE XT-E 9W 230Vac,

with lens 27°, 3000K, 600lm

700mA Power supply included



T004 LB K4

LED module 3 CREE XT-E 9W 230Vac,

with lens 27°, 4000K, 700lm

700mA Power supply included

 LED INSIDE Classe I Energy saving Protection index IP20 Led CE marking Inflammable surfaces (F)

T004 LA K3

LED module 3 CREE XT-E 8W 700mA,

with lens 27°, 3000K, 600lm

Power supply not included



T004 LA K4

LED module 3 CREE XT-E 8W 700mA,

with lens 27°, 4000K, 700lm

Power supply not included

 LED INSIDE Classe III Energy saving Protection index IP20 Led CE marking Inflammable surfaces (F)

COLORS

BOX:
ral customization

ACCESSORIES / COMPONENTS
Teseo suspension LED lamp

TE079
Driver 500mA 12W
Teseo suspension LED lamp

TE049
Driver 500mA 25W
Teseo suspension LED lamp

TE052
Driver 700mA 8W

Teseo suspension LED lamp

TE072
Driver 700mA 20W

DOCUMENTATION

Technical Drawing

Data Sheet

Electrical Assembly Instructions
